Aluminum LED lighting pole Gumlog
More info
Inspired by LP Skot (not replica LP Skot)
Due to the copyright notice, please note that this product is not a replica
Inspired by: LP Skot
Product description
Thanks to the opal screen, the fixture emits soft, comfortable and symmetrical light. Thanks to the transparent, semi-shaded screen, the luminaire emits glare-free, symmetrical light directed downwards. The half-curtain helps direct the light.
Installation
Terminal strip location: In the fixture head. Loop: Approved, max. 4x2.5mm². Ballast location: In the device head. Max. installation cable: 1 pc. 4x2.5mm² or 2 pcs. 4x1.5mm². U-shaped post for underground installation: Height with handle: 1438 mm, including 600 mm underground. U-shaped post with surface mount base plate: Height including bracket: 838 mm. When installing one luminaire, the depth is: 220 mm, with 2 luminaires (double installation): 331 mm.
Technical note
The innovation of light sources is ongoing. Therefore, we only inform about max. powers. At www.louispoulsen.com we update the list of recommended light sources.
Finish
Colored aluminum or graphite with a textured surface, powder coated.
Light source and energy class
Energy class
/>LED light source 3000K 8.5W
Materials
Injection molded clear polycarbonate or injection molded opal polycarbonate. Base/cross cover: Die-cast aluminum. U-pillar: extruded aluminum.
Class
IP66 protection rating. Electric shock protection II without grounding. IK10.
Technical data
Width x height x length (mm)
316 x 838 x 220 Max. 3.0 kg
Tags
LP, Skot, Outdoor Lighting, Light Bollards, Lighting, Light Bollards, Contemporary Style Bollards, Aluminum Bollards, Metal Bollards, LED Bollards
