Inspired by Proled 1R MONO (not replica Proled 1R MONO)
Due to the copyright notice, please note that this product is not a replica
Inspired by: Proled 1R
Product description
The PROLED INGGROUND series is designed to be integrated with the floor and offers various possibilities for architectural lighting design. Dimmable and controllable via DMX 512, DALI, KNX, 1-10 V, CASAMBI, RF by MULTI or PRO CONTROLLER power supplies incl. PVC mounting sleeve TECHNICAL DATA IP Rating IP67 (for outdoor use) 24 VDC Power Source 316 Stainless Steel Ring Housing powder-coated gray aluminum, 7 mm tempered glass Mounting sleeve PVC material Load capacity full surface = 1700 kg Electrical connection 1x cable 0.5 m H05RN-F 2x 1.0 mm² for open cables Average life 50,000 h at L80/B10 Operating temperature range -10° C to +45° C PHOTOMETRIC DATA LED type OSRAM 2 W, high power Luminous flux warm white 160 lumens Color temperature warm white 3000 K CRI80 Light angle 30° and asymmetric 45°/35°
