Inspired by Metalmek Hi-Panel 9940 Mp (not replica Metalmek Hi-Panel 9940 Mp)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Metalmek Hi Panel
Original code: 9940 OP

Product description

HI-PANEL 9940 MP is a built-in ceiling lamp made of extruded aluminum, painted with SOLVENT-FREE, semi-bright white epoxy-polyester powders, thermosetting at 180°C, after phosphating. Microprismatic methacrylate diffuser.
Mountings:
• Recessed luminaire, recessed installation in exposed supporting structure 600x600 mm wide.
• Recessed luminaire, installation in plasterboard ceilings according to: 9952 -100 (595x595), 9952-200 (295x1195)
• Built-in fitting, surface mounting in an exposed supporting structure, 625x625 mm wide, acc. 9951-623B (595x595)
• Surface-mounted luminaire, with: KIT-PLAF9940-4 (595x595), KIT-PLAF9940-2 (295x1195)
• Suspended luminaire, with: KIT- SOSP9940-4 (595x595), KIT-SOSP9940-2 (295x1195)
Light emission: direct, symmetrical
Housing: Made of extruded aluminum, painted with SOLVENT-FREE, semi-bright white epoxy-polyester powders, thermosetting at 180 °C, after phosphating
Optical device: Microprismatic methacrylate diffuser
Light source:
• LED CRI ≥90 Ra
• 4000K
• Lifespan (hours) 50,000 (-30° 1 +70 °C - Ta=25°C) L70B10
Wiring: Class III
Power supply (independent LED driver) 100~240 V / 50-60 Hz
Efficiency data: Efficiency A+
Protection level: IP43
Suitable for environments with displays according to EN 12464-1
UGR ≤19
200.000 cicli di accensione
Markings: CE
Regulations :
EN 60598-1
EN 60598-2-1
EN 60598-2-2
EN 62031
Photobiological safety of lamps and lamp system:
EN 62471
IEC/TR 62778
Exempt risk - GR 0
Directives:
2014/35/EU
2014/30/EU
VERSIONS ON REQUEST (if possible):
• Dimmable electronic ballast
• Dimmable DALI electronic ballast
• Emergency unit 1h
