Aluminum LED hanging lamp Vinuesa

More info

Inspired by Metalmek Vector A 9809 MP (not replica Metalmek Vector A 9809 MP)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Metalmek Vector A
Original code: 9809 MP

Product description

VECTOR A 9809 MP is a hanging lamp made of extruded aluminum, painted WITHOUT SOLVENTS in white, black, gray or other colors to order, with epoxy-polyester powders, thermosetting at 180°C, after phosphating. Removable hardware plate on which the wiring elements are mounted, made of extruded aluminum, painted WITHOUT SOLVENTS, with white epoxy-polyester powders, thermosetting at 180°C, after phosphating.
Mountings: Suspended mounting
Light emission : direct / indirect, symmetrical
Body Made of extruded aluminum, painted WITHOUT SOLVENTS, with white or black epoxy-polyester powder, thermosetting at 180°C, after phosphating
Wiring plate Removable wiring plate made of powder-coated extruded aluminum epoxy-polyester in white, thermosetting at 180°C, with surface pre-treatment with phosphating
Head Made of printed interlocking aluminum
Optical device
Microprismatic diffuser made of polycarbonate - (direct)
Opal polycarbonate diffuser - (indirect)
Light source: LED
CRI ≥ 80
3000K
4000K
Color tolerance: 3 - MacAdam (3 SDCM)
Lifespan: 80000 hours - L80B20
Wiring: Class I
Power supply 220 ~ 240 V / 50-60 Hz
Efficiency:
• Efficiency A+
• Degree of protection : IP20
Marks: CE
Regulations:
EN 60598-1
EN 60598-2-1
EN 62031
Photobiological safety of lamps and lamp system:
EN 62471
IEC/TR 62778
Exempt risk - GR 0
Directives:
2014/35/EU
2014/30/EU
VERSIONS ON ORDER
• DALI dimmable electronic ballast
• 1h emergency unit
• LED CRI ≥ 90
