Aluminum LED hanging lamp Vinuesa

More info

Inspired by Metalmek Vector A D-I 9808 PAR99 (not replica Metalmek Vector A D-I 9808 PAR99)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Metalmek Vector A
Original code: 9808 PAR99

Product description

VECTOR A DI 9808 PAR99 is a hanging lamp with a body made of extruded aluminum, painted with SOLVENT-FREE epoxy-polyester powders, thermosetting at 180°C, after phosphating. Removable hardware plate on which the wiring elements are mounted, made of extruded aluminum, painted with SOLVENT-FREE, white, thermosetting at 180°C, after phosphating. Darklight louvre, double parabolic, with parabolic lamellas closed at the top, made of high-gloss anodized aluminum, anti-reflective and anti-iridescent. Glare reduction.
Mountings: Suspended mounting
Light emission: Direct / indirect, symmetrical
Body Made of extruded aluminum, painted with SOLVENT-FREE white or black epoxy-polyester powders, thermosetting at 180° C, after phosphating
Wiring plate Removable wiring plate made of extruded aluminum, painted with white epoxy-polyester powders, thermosetting at 180°C, with phosphated initial surface
Head Made of printed aluminum, interlocking
Optical device Lamella optics Darklight, double parabolic in aluminum, mirror, anti-reflective, anti-roidizing, with parabolic lights closed at the top, very low luminance - (Direct)
0.2mm opal PMMA protective screen - (Direct)
Opal shade made of polycarbonate - (indirect)
Light source: LED
CRI ≥ 80
3000K
4000K
Color tolerance: 3 - MacAdam (3 SDCM)
Lifespan : 80000 hours - L80B20
Wiring: Class I
Power supply 220 ~ 240 V / 50-60 Hz
Efficiency:
• Efficiency A+
• Degree of protection: IP20
Marks: CE
Regulations:
EN 60598-1
EN 60598-2-1
EN 62031
Photobiological safety of lamps and lamp systems:
EN 62471
IEC/TR 62778
Exempt risk - GR 0
Directives:
2014/35/EU
2014/30/EU
VERSIONS FOR ORDER
• DALI dimmable electronic ballast (if possible)
• Emergency complex 1h
• LED CRI ≥ 90
