Inspired by OLI Easy MOVE (not replica OLI Easy MOVE)

Due to the copyright notice, please note that this product is not a replica

Inspired by: OLI Easy

Product description

Easy Move allows you to change the height of the bowl depending on the user's needs thanks to an extremely attractive solution. Easy Move is particularly suitable for people with disabilities: for this reason it is also optionally equipped with a set of handles for disabled people; Moreover, the flush can be started using a special control panel. The Easy Move frame is compatible with all toilet models available on the market and guarantees a height modification of up to 150 mm, starting from a minimum height of 400 mm and reaching a maximum height of 550 mm; the structure is 200 mm deep, including the tank and actuating motor. The engine is extremely powerful with a thrust of over 600 kg and ensures maximum reliability and silence: during operation, the engine noise is practically inaudible. The Easy Move design also includes a flexible flush pipe and has a movement speed of 12 mm/s, allowing you to quickly change the height of the toilet bowl. The front finish of the Easy Move structure is based on the use of a tempered glass panel, offers a choice of colors: black or white.
CHARACTERISTICS
- Adjustable frame with a dual flush cistern OLI74 PLUS 6/3 liters;
- Ergonomic system with the possibility of adjusting the height in the range of 150mm;
br />- Quiet electric motor;
- Mains power supply: 220 V/110 (50/60 Hz);
- Power: 350 W;
- Insulation degree: IP66;
- Movement speed: 28mm/s;
- Pushing force: 6000N (approx. 600kgf);
- Pulling force 3000N (approx. 300kgf) ;
- Limit switch;
- Tested frame for a load of 400kg;
- Easy and quick installation thanks to the quick mounting system;
- Tempered glass front cover available in black or white (6x400x1345mm);
- Frame and glass are sold separately;
- Flush plate is not included;
- Global warranty 10 years and 2 years for electronic components.
In INCLUDED
- Wireless remote control;
- Wall mounting material and toilet mounting material;
- Toilet inlet and outlet connections.
