Inspired by Proled Xl Rgbw Dmx (not replica Proled Xl Rgbw Dmx)

Due to the copyright notice, please note that this product is not a replica

Product description

PROLED WALLWASHER XL RGBW is ideal for illuminating large surfaces, e.g. buildings or walls in outdoor areas. Thanks to high-power RGBW LEDs (10 W), WALLWASHER XL RGBW ensures uniform color mixing and pure, natural white.
WALLWASHER XL RGBW can be directly controlled by DMX 512 (4, 5, 7, 8 or 10-channel DMX mode):
- 19 independent programs (3 editable)
- Master - possible operation in Slave mode
- No flicker (1 kHz technology) - ideal for TV studios
- including configuration device (DMX addressing, configuration, stand-alone programs)
TECHNICAL DATA
IP classification IP65 (for outdoor use)
Power source 100-240 VAC 50/60 Hz
Housing powder black coated aluminum
Electrical connection
1x cable 2 m H07RN-F 3x 1.5 mm² with F-type male plug
1x DMX cable 0.5 m with XLR 5-PIN plug
1x DMX cable 0.5 m with female XLR 5-PIN connector
Average life 50,000 h at L80/B10
Operating temperature range -10° C to +45° C
PHOTOMETRIC DATA
LED type CREE MC-E RGBW module 10 W
Luminous flux
red 3320 lumens
green 6440 lumens
blue 1260 lumens
white 9020 lumens
r+g+b+w 19600 lumens
Wavelength
red 620 nm
green 525 nm
blue 460 nm
Color temperature white 6500 K
/>Beam angle 20°
