Corten™ LED lighting pole Taxach
More info
Inspired by LP Bysted (not replica LP Bysted)
Due to the copyright notice, please note that this product is not a replica
Inspired by: LP Bysted
Product description
The fixture emits light directed downwards. The lampshades have a lower surface painted white, which ensures optimal light reflection and creates a characteristic symmetrical light pattern around the fixture.
Installation
Struts in the ground: Yes. Terminal strip location: On the post. Loop: approved, max. 5x6mm². Driving position: Top pole position. Max. installation cable: Depending on the junction box. Pole/in-ground installation: H: 1445 mm excl. luminaire head, part buried in the ground: 600mm. Post with base plate for surface mounting: H: 845mm without base mounting head. Post Wed. 200mm.
Light source and energy class
Energy class
LED light source 3000K 24W
Finish
Corten steel, raw.
Materials
Fixture Head: Pressure cast iron. Post: corten steel. Base plate: corten steel.
Class
Degree of protection IP65. Electric shock protection II without grounding. IK09.
Technical data
Width x height x length (mm)
280 x 1130 x 280 Max. 44.5 kg
