Inspired by Cariboni Group M48 Area (not replica Cariboni Group M48 Area)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Cariboni Group M48

Product description

Versatile, modular, high-performance, ceiling-mounted LED system, ideal for lighting commercial and industrial spaces, walkways and covered parking lots. The number of LED modules can vary from one to three, depending on the level of performance required. Possibility to replace any LED module without having to manually disconnect the power, because there is no wiring between the modules. Possibility of mounting the luminaire directly to the busbar using a set of brackets supplied with all busbar systems available on the market. A ceiling mounting suspension system with cables and brackets is available. Connecting the system to the line is quick, easy and tool-free because the product does not need to be opened. The product is supplied with a DALI dimming system and an emergency system. The emergency system operates when connected to a centralized switching system between the 230 V line and the DC line, guaranteeing a minimum flux of 15% and a maximum flux of 60%. Colors: gray RAL 9006 or white RAL 9003. Optics: square large QU-D beam, rectangular asymmetric large RE-AD beam and rectangular focused RE-C. CRI (color rendering index): Ra ≥ 70. Average LED life 80, [email protected] @ Ta25°C TM21. Compatible control systems: motion sensors, presence and light sensors, controlled by the DALI protocol. Two- and three-module versions can be powered by separate controllers. Luminaire without photobiological risk (EXEMPT GROUP) compliant with the EN 62471:2008 standard and subsequent IEC/TR 62471:2009. Classification: CUT OFF.
Nominal voltage 230 V 50 Hz
Insulation class Class II
IP protection level IP66
Impact protection IK08
Color temperature 4000 K
>Weight 14.00 kg, 18.50 kg, 7.60 kg
ENEC / CE labels and certificates
5-year warranty for LED fixtures
