Inspired by PUK Frame (not replica PUK Frame)

Due to the copyright notice, please note that this product is not a replica

Original code: 402801,02,03,04

Product description

Frame is an outdoor LED wall lamp made of glass and aluminum. Available in 4 variants.
· Material Copper-free extruded aluminum body with high corrosion resistance
· Coating Polyester powder coating with phosphor pre-finish
· Screws Stainless steel
· Transformer Power supply electronic power supply
· 220/240V 50/60Hz built-in
· Gasket Silicone rubber
· Glass Acid-etched tempered glass
· Diffuser painted white on the inside
· Power cable 0.3 mt. power cable included
402801 MEDIUM ROUND FRAME
Round dia. Surface-mounted luminaire with a diameter of 210 mm for external mounting on a facade/wall. Copper-free phosphochromatized polyester powder-cast body, acid-etched tempered glass diffuser, internally painted white, molded silicone gasket and stainless steel screws. Built-in LED driver 220-240 V 50-60 Hz, with 36 medium power SAMSUNG 2835 diodes. Degree of protection IP65.
402802 MEDIUM SQUARE FRAME
Square surface-mounted luminaire with dimensions of 200x200mm for external mounting on the facade/wall. Copper-free phosphochromatized polyester powder-cast body, acid-etched tempered glass diffuser, internally painted white, molded silicone gasket and stainless steel screws. Built-in LED driver 220-240 V 50-60 Hz, with 36 medium power SAMSUNG 2835 diodes. Degree of protection IP65.
402803 MAXI ROUND FRAME
Round diameter. Surface-mounted luminaire with a diameter of 285 mm for external mounting on a facade/wall. Copper-free phosphochromatized polyester powder-cast body, acid-etched tempered glass diffuser, internally painted white, molded silicone gasket and stainless steel screws. Built-in LED driver 220-240V 50-60Hz, with 48 SAMSUNG 2835 medium power diodes. Degree of protection IP65.
402804 FRAME MAXI SQUARE
Square surface-mounted luminaire with dimensions 270x270mm for external mounting on the facade/wall. Copper-free phosphochromatized polyester powder-cast body, acid-etched tempered glass diffuser, internally painted white, molded silicone gasket and stainless steel screws. Built-in LED driver 220-240V 50-60Hz, with 48 SAMSUNG 2835 medium power diodes. Degree of protection IP65.
