Inspired by Proled Xtend Rgb (not replica Proled Xtend Rgb)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Proled Flex Strip

Product description

All the advantages of Flex Strips extend up to a length of 20 m. PROLED Flex Strip Xtend RGB is perfect for large rooms and long walls that can be illuminated with continuous light quality.
- Excellent light quality and color rendering and - thanks to technology 48 V – even dimming along the entire length
- Perfect for halls, corridors and long walls
- Suitable for ambient lighting, orientation and accent lighting
- Only one power source needed for a length of 20 m
- Significantly reduced installation effort
- Dimmable with appropriate PWM dimmers
TECHNICAL DATA
IP20
Power source 48 VDC
Electrical connection 2x cable for open wires; 4-pin; 30 cm
Maximum quantity for power consumption 20 m
Average life 50,000 h
Operating temperature range -10° C to +45° C
Width x height 14 x 2 mm< br/min. Bending radius 20 mm
Possibility to cut all 13 LEDs (16.7 cm)
PHOTOMETRIC DATA
LED type SMD RGB 3-in-1 LEDs
Luminous flux
red 120 Lumens per m
green 300 lumens per m
blue 70 lumens per m
RGB 490 lumens per m
Wavelength
red 620 nm
green 525 nm
blue 470 nm
Beam angle 120°
