Inspired by Timberlab Sotto (not replica Timberlab Sotto)

Due to the copyright notice, please note that this product is not a replica

Product description

SOTTO is a luminaire designed for mounting on walls or bushes, ideal for public spaces and recreation centers. The luminaire has a waterproof frame integrated with the pole, which ensures a solid structure. It is made entirely of solid oak, larch or chestnut with a diameter of 20 cm. The natural and solid appearance of the SOTTO luminaire makes it invisible during the day, and at night it is an optimal source of illumination for objects, trees and bushes.
The luminaire is equipped with a GU10 light source and is supplied with a standard 1.0 m cable. m. Options without a cable or a junction box with a hole for two ground cables are also available. SOTTO provides a choice of light colors, including 2700, 3000 or 4000K. It is easy to install and other dimensions are possible.
TECHNICAL DATA
• Thickness: 200 mm
• IP protection level: IP54
• Voltage: 230 V
• Power supply per LED module: 5 W (LED PAR16 reflector lamp with a GU10 base)
• Luminous flux per LED module: 480 lm
• Light distribution angle: 40 degrees
OPTIONS
• Wood type: Larch/Douglas (only on base support), Oak, Rustic Chestnut or Accoya
• Quality mark: FSC or PEFC
• Accessories: BASSO is available with or without a post holder. All technical data of the various post holders can be found in the "Post mounts" chapter.
• Light color: Available in temperatures of 2700, 3000 K and 4000 K.
• Connection: Possible with or without cable (1 m 3x 1.5 mm2). A 32 mm diameter hole is standard for easy passage of the ground cable.
Lightings are an important element of Timberlab lighting solutions, mainly used to accentuate walls, trees and buildings. These fixtures use a waterproof LED soil reflector, making the post sturdy. The modern and natural aesthetics of the frame make it unobtrusive during the day. However, during night hours it serves as an excellent source of lighting for any environment.

Technical data

19x19x40cm
