Aluminum linear lighting profile for LED modules Rheine
More info
Inspired by Essenzialed Wall Washer (not replica Essenzialed Wall Washer)
Due to the copyright notice, please note that this product is not a replica
Product description
Wall Washer is a linear LED lighting profile used to illuminate and create lighting effects. Thanks to 6 different optics and an adjustable bracket, it is possible to evenly illuminate any type of wall up to 13 meters high.
Wallwasher is available with white or colored light. This product is cULus Listed for the US and Canadian markets.
Technical data
Material Aluminum
Weight 1000 g
Length 500 mm
IP rating IP20
Electrical technical data
Remote power supply
Supply voltage 24 Vdc
Total power 19 W
Light source
Type of LED source
LED absorption module 19 W
Color temperature 2700 K 3000 K 4000 K
Nominal LED flux 1632 lm 1700 lm 1742 lm
LED module efficiency 85 lm/W 89 lm/W 91 lm/W
LED efficiency class G
Lifespan L80/ B10 (25 °C) > 50,000 h
Device
Color temperature 2700 K 3000 K 4000 K
Luminous flux 1370 lm 1428 lm 1463 lm
Efficiency LED lamps 72 lm/W 75 lm/W 77 lm/W
Red saturation index (R9) >50
Color rendering index (Ra) 80
SDCM 3
Optical system characteristics
Lens material PMMA
