LED track lamp made of extruded aluminum Svitiaz
More info
Inspired by Letroh Nodo STRIP LED (not replica Letroh Nodo STRIP LED)
Due to the copyright notice, please note that this product is not a replica
Inspired by: Letroh Nodo
Product description
The shape of the rail has been designed to easily and invisibly integrate flexible, optional LED STRIPES.
When the rail is suspended from the ceiling, the LED STRIP is in the Up Light position, providing indirect ambient lighting.
When the rail is suspended from the ceiling, the LED STRIP is in the Up Light position, providing indirect ambient lighting. mounted on a horizontal or vertical surface, the LED STRIP creates diffused lighting of the floor thanks to the position of the side light.
Technical data
STRIP LED
15301 3000K
15302 4000K
Flexible LED strip, dimmable.
Mounting to the rail with integrated double-sided tape.
Can be cut to size [protection level from IP44 to IP20].
210 LED/mt – 10W/mt – 24V
The shape of the rail has been designed to integrate flexible LED strips with easily and without seeing them.
When the track is suspended from the ceiling, the LED STRIP is in the Up Light position, providing indirect ambient lighting.
When the track is mounted on a horizontal or vertical surface, the LED STRIP is placed in the Up Light position Side Light position, which provides diffused illumination of the surface.
The electrical installation is independent of the system.
Net weight Kg 0.13 [5 mt]
IP 44
End power supply for STRIP LED
RIGHT end power supply
25040 Satin silver
25140 Polished silver
25340 White
LEFT End Power Supply
25042 Satin Silver
25142 Polished Silver
25342 White
Integrated Constant Voltage Output Power Supply
240V AC INPUT 50/60 Hz
OUTPUT 24V – 50W
Net weight Kg 0.38
IP 20
>
Power supply for STRIP LED
25120 70 W
Power supply with constant voltage output. It must be placed in a remote place from the installation performed using the NODO system [the electrical installation is independent of the system].
INPUT 240V AC 50/60 Hz
OUTPUT 24V – 70W
Net weight Kg 0.30 [70 W]
IP 20
