Inspired by Essenzialed Quadro TRACK (not replica Essenzialed Quadro TRACK)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Essenzialed Quadro

Product description

Quadro Track Compact linear lamp with high brightness. Thanks to a special mechanical system, it can be rotated 355°, creating unique lighting effects. Available in ON/OFF version, dimmable via CASAMBI and DALI.
Technical data
Material Aluminum
Weight 1090 g
Ingress protection IP20
Electrical specifications
Power supply unit Included - ON/OFF
Supply voltage 220 V - 240 V
Power frequency 50 - 60 Hz
Total power 33.5 W
Dimmable Casambi - Dali
Light source
Type of LED source
Minimum voltage in the secondary circuit 42 V
LED absorption module 30.4 W
Color temperature 2700 K 3000 K 4000 K
Nominal LED flux 4741 lm 4887 lm 5061 lm
LED module efficiency 155 lm/W 160 lm/W 166 lm/W
LED efficiency class D
Durability L80/ B10 (25°C) ) > 50,000 h
Device
Power supply 33.5 W
Color temperature 2700 K 3000 K 4000 K
Luminous flux 2654 lm 2736 lm 2834 lm
LED lamp efficiency 79 lm/W 81 lm/W 84 lm/W
Red saturation index (R9) >60 >70 >80
Color rendering index (Ra) 95 SDCM 3
Optical system characteristics
Lens material Polycarbonate
