Inspired by Essenzialed Pwxl Dark Track-S (not replica Essenzialed Pwxl Dark Track-S)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Essenzialed PWXL

Product description

PWXL DARK Track-S is a suspended linear lamp with a DARK diaphragm with very low glare and an average UGR coefficient of 12. Available in an ON/OFF version with the possibility of dimming via Casambi and DALI.
Technical data
Material Aluminum
Weight 3296 g
Length 1700 mm
IP protection level IP20
Electrical technical data
Power supply Included - ON/OFF
Supply voltage 220 V - 240 V
Power frequency 50 - 60 Hz
Total power 52 W
Dimmable Casambi - Dali
Light source
Type of LED source
Minimum voltage in the secondary circuit 42 V
LED supply current 1050 mA
LED absorption module 46W
Color temperature 2700 K 3000 K 4000 K
Nominal LED flux 7111 lm 7330 lm 7591 lm
Module efficiency LED 155 lm/W 159 lm/W 165 lm/W
LED efficiency class D
Duration lifespan L80/ B10 (25 °C) > 50,000 h
Device
Color temperature 2700 K 3000 K 4000 K
Luminous flux 2844 lm 2932 lm 3036 lm
LED lamp efficiency 55 lm/W 56 lm/W 58 lm/W
Red saturation index (R9) >60 > 70 >80
UGR 12
Color rendering index (Ra) 95
SDCM 3
Optical system characteristics
Lens material Polycarbonate
