Inspired by Vibia Tube (not replica Vibia Tube)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Vibia Tube
Original code: 6100610561106110

Product description

Tube by Ichiro Iwasaki presents a collection of lamps in which the suspension option can be supplemented with a ceiling version or another combination, adapted to the requirements of any architectural space with variable spot and mood lighting. The lighting system smoothly directs light extending horizontally and vertically to different heights.
Installation type
Surface canopy
Diffuser
Polycarbonate lampshade
Materials
Ceiling rosette: Steel
LED bracket: Aluminum
Tube 6100
Electrical characteristics
Led 2700K CRI >90 1740 lm 128.8 lm/W
Lamp 632 lm 46.81 lm/ W
Contains controller: CC - direct current 700 mA 110~240V 50/60Hz
Photometric data
Efficiency: 39.65 lm/W
Coordination system: CG
Total flux: 631.96 lm
Maximum value: 259.67 cd
Fluorescent lamp 6105
Electrical characteristics
Led 2700K CRI >90 2900 lm 145 lm/W
Lamp 1169.9 lm 58.49 lm/W
Contains controller: CC - direct current 700 mA 110~240V 50/60Hz
Photometric data
Efficiency: 48.13 lm/W
Coordination system: CG
Total flux: 1169.89 lm
Maximum value: 433.69 cd
Tube 6110
Electrical characteristics
Led 2700K CRI >90 3480 lm 139.2 lm/W
Lamp 1447.5 lm 57.89 lm/W
Contains controller: CC – direct current 700 mA 110~240V 50/60Hz
Photometric data
Efficiency: 51.14 lm/W
Coordination system: CG
Total flux: 1447.46 lm
Maximum value: 576.19 cd
Tube 6115
Electrical characteristics
Led 2700K CRI >90 8120 lm 138 lm/W
Controller included: CC - direct current 700 mA 110 ~240 V 50/60 Hz
Technical characteristics
Main input via greatest shade
Photometric data
Effectiveness: 47.41 lm/W
Coordination system: CG
Total flux: 3249.68 lm
Maximum value: 1269.56 cdJapanese designer Ichiro Iwasaki has created an innovative lighting system: a network of tubes that direct light from a specific single point to various lampshades that can be positioned as needed. Light is guided by precise design and at the same time provides interior designers and architects with unlimited freedom to generate various configurations. Tube offers a unique landscape of shadows and light channels, a grid reminiscent of the urban sphere that combines aesthetics and optimal functionality.
“The name of the collection comes from the system of tubes, but also generated lines and intersections that resemble the typical way of illustrating maps subway or subway,” notes Ichiro Iwasaki.
Tube draws attention to the installation itself, highlighting what is usually hidden, included, as if it were a compositional element. But most importantly, it can direct light to four separate points with a single switch. A study that facilitates the planning of lighting projects, in which Vibia is a pioneering company. The urban spirit of the Tube is emphasized by the color options of aluminum shades, including three different shades of gray: light, medium and graphite, as well as off-white. Made in four different dimensions with the possibility of combining if necessary, from 22 to 53 cm, matching colors, mounted at different heights and distances from each other. The suspension option can be supplemented with a ceiling version or another combination, adapted to the requirements of any architectural space with variable spot and mood lighting.
