Aluminum LED hanging lamp Orgtrud

Product description
Reviews

More info

Inspired by Metalmek Tile-D 9747 (not replica Metalmek Tile-D 9747)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Metalmek Tile
Original code: 9747 MP

Product description

TILE-D 9747 has a body made of extruded aluminum, painted with SOLVENT-FREE, white, black, gray or other color to order, with epoxy-polyester powders, thermosetting at 180°C, after phosphating. Removable accessory plate on which the wiring elements are mounted, made of extruded aluminum, painted with white epoxy-polyester powders free of solvents, thermosetting at 180°C, after phosphating.
Mountings:
• Surface-mounted fixture
• Suspended luminaire acc. to 4406 + 4417-SP2
Light emission: Direct, symmetrical
Body: Made of extruded aluminum, painted WITHOUT SOLVENTS, white, black, gray or other on request, epoxy-polyester powders, thermosetting at 180° C, after phosphating.
Removable hardware plate on which the wiring elements are mounted, made of extruded aluminum, painted with SOLVENT-FREE, white epoxy-polyester powders, thermosetting at 180°C, after phosphating.
Optical device: Transparent microprismatic polycarbonate diffuser
Light source: LED CRI ≥80 Ra
• 3000K
• 4000K
• Color tolerance 3 MacAdam (3 SDCM)
Wiring: Class I
/>Power supply 220~240 V / 50-60 Hz
Performance data: Efficiency A+
Protection level IP20
Lifespan (Ta=25°C) 50000h L80B10
UGR ≤19
Marks: CE
Regulations:
EN 60598-1
EN 60598-2-1
EN 62031
Photobiological safety of lamps and lamp system:
/>EN 62471
IEC/TR 62778
Exempt risk – GR 0
Directives:
2014/35/EU
2014/30/EU
VERSIONS ON REQUEST (if possible)
• Dimmable electronic ballast
• DALI dimmable electronic ballast
• 1h emergency unit
• Ra 90
