Inspired by Proled Linear XL (not replica Proled Linear XL)

Due to the copyright notice, please note that this product is not a replica

Inspired by: Proled Linear

Product description

The LINEAR XL series of fixtures is universally applicable and is available in 720 different versions. Each version is also available with an indirect light beam (Uplight) in RGBW or monochromatic mode (4 color temperatures). Just in time production within approx. 3 to 10 days (depending on quantity).
-5 lengths: 604 mm, 894 mm, 1174 mm, 1534 mm and 1964 mm
- 3 colors: aluminum silver, white and black
- 4 lampshades: crystal clear, frost (semi-transparent), milky (opal) and with a micro-prism
- 3 power classes: BASIC (2 strips), MEDIUM (3 strips) and FORTE ( 4 stripes)
- 4 color temperatures: white (6000 K), neutral white (4000 K), warm white (3000 K) and super warm white (2700 K)
- optional with indirect light flux ( Uplight) in RGBW mode - control via RF Remote
- optionally with indirect light flux (Uplight) in white (6000 K), neutral white (4000 K), warm white (3000 K) or super warm white (2700 K) – separate connection cable for separate ON/OFF switching
TECHNICAL DATA
IP20
Power source 220-240 VAC 50/60 Hz
Electrical connection
without options:
1x cable 3 m H05VV-F 3x 1.0 mm² or with welded connectors
with Uplight RGBW option:
1x cable 3 m H05VV-F 5x 1.0 mm² or with welded connectors
with monochrome Uplight option:
1x 3 m cable H05VV-F 5x 1.0 mm² or with splice connectors (2x)
Average lifespan 50,000 h at L80/B10
Operating temperature range -10° C to +45° C
Width x height
without Uplight option: 76 x 76 mm
with Uplight option: 76 x 84 mm
PHOTOMETRIC DATA
SMD LEDs 5630/5730
Color temperature
white 6000 K
neutral white 4000 K
warm white 3000 K
super warm white 2700 K
CRI90
Light distribution angle 120° (direct luminous flux)
