Inspired by LP LP Grand (not replica LP LP Grand)

Due to the copyright notice, please note that this product is not a replica

Inspired by: LP LP Grand

Product description

The circular fixture is viewed as a set of converging rings set around a centrally placed horizontal diffuser. A large, angular reflector surrounds the diffuser and reduces contrast around the edges. The swiveling top reflector is perfectly curved to spread light from above at a wide angle. The colored outer shade surrounds the reflector and creates a mutual reflection of light, resulting in a graceful glow of light outside the upper and lower reflectors. In total, it creates four rings of light surrounding the central diffuser.
Finish
Reflector: matte white satin finish. External shade (outside): Matt (black and champagne) or glossy (white). Wet painted surface. Lampshade: Glossy.
Materials
Ø320: Upper reflector: ABS. Lower reflector: ABS. External shade: ABS. Diffuser: PMMA. Housing: Cast aluminum. Ø580: Upper reflector: ABS. Bottom reflector: PE. External shade: ABS. Diffuser: PMMA. Housing: ABS.
Ø880: Top reflector: PE. Bottom reflector: PE. External shade: ABS. Diffuser: PMMA. Housing: ABS.
Ø1480: Upper reflector: PE. Bottom reflector: PE. External shade: PUR. Diffuser: PMMA. Housing: ABS.
Installation
Ø320: Suspension type: 2 x 0.75 mm² cable with cable and 3 cables. Canopy: Yes. Controller integrated with the canopy. Cable length: 4 m. Loop: max. 5 x 2.5 mm².​
Ø580/Ø880: Suspension type: Cable 5x0.75mm² with cable and wire. 1x5x0.75mm² with cable and 3 wires. Canopy cover: Yes. Cable and wire length: 4 m. Loop: No.
Ø1480: Suspension type: 5x0.75mm² cable with cable and wire. 2x5x0.75mm² with cable and 4 wires. Canopy cover: No. Cable and wire length: 4 m. Looping: No.
Light source
LED light source 3000K 59W - Lumen: 5225
Class
Protection level IP20. Protection against electric shock and grounding.

Technical data

Width x Height x Length (mm)
320 x 90 x 320 mm - Max. 0.0 kg
580 x 160 x 580 mm - Max. 6.3 kg
880 x 200 x 880 mm - Max. 16.6 kg
1480 x 260 x 1480 mm - Max. 45.0 kg
